wilo stn 32 160b

Wilo STN range

Hydraulics

Hydraulic system with axial suction ports, radial discharge ports and bearing brackets as a single unit. The connections are configured as flange connections.

Seal

Bearing bracket with sealing and leakage chamber for admission of fluid ingress via the seal. Fluid-side seal via a bidirectional mechanical seal, motor-side seal as a rotary shaft seal. The sealing chamber is filled with medical white oil, the leakage chamber is shut up to the motor. Optionally, the sealing chamber can be monitored with an external pencil electrode.

Motor

IEC standard motor in B5 design as three-phase motor with motor efficiency class IE3.
