SamKing A/D-4SPW2-13P Pump/Motor/Controller Pump/Motor/Controller
Original price was: R21 474,18.R12 562,39Current price is: R12 562,39.
1.5-Inch 2200W AC/DC Solar Submersible Pump for Community Water Supply
Model: SAMKING A/D-4SPW2-13P-A (198m | 5.7m³/h | 450V | 2200W)
The SAMKING Solar Pump is a high-performance, centrifugal AC/DC solar pump with a built-in controller, designed for long-lasting use in community water supply systems. This model is known for being both cost-effective and practical, making it an ideal solution for larger-scale water delivery needs.
It includes a one-year warranty for both the DC solar pump and the DC controller.
Please note: Solar panels are not included in the package.
Important Information:
-
Recommended: Use 550W solar panels connected in series
-
The controller is IP65-rated, but it is not recommended to mount it in direct sunlight
-
VOC (Volts Open Circuit) = voltage when not connected to a load
Vmp (Voltage at Maximum Power) = voltage under load -
Exceeding specified limits may result in serious damage or irreversible failure
Solar Water Pump Motor Details
Power:2200W
Material: AISI 304
Type: BLDC motor
Feature: Encapsulated water filled
Bearing: Thrust bearing system
Current: Max. DC 15A
Submersion: Max. 150m
Water Temp: Max. 40°C
Efficiency: Max. 85%
Insulation Class: F
Max Voltage: DC Max. VOC 100V
Optimal Voltage: DC Best. Vmp 40-90V
Max Speed (Plastic): 4500 RPM
Max Speed (SS304): 4000 RPM
Max Speed (Helical): 4000 RPM
Enclosure Class: IPX8
Required Cooling Flow: 0.5L/s
PROTECTION TYPE
Dry-Run: Yes
Reverse: Yes
Phase Loss: Yes
Over-Voltage: Yes
Low-Voltage: Yes
Over-Current: Yes
Over-Load: Yes
Over-Power: Yes
Over-Temperature: Yes
Stall: Yes
Error Display: Yes
Solar Water Pump Controller Details
Function: Voltage/current/power display
Voltage: 40-90Vmp/100Voc
MPPT Efficiency: Max.98%
Enclosure Class: IP65
Solar Product Advantages:
/ Stainless Steel-AISI 304 (316 Optional)
/ BLDC High Efficiency Motor
/ External Controller
/ Powered by DC Power Only
/ Voltage/Current/Power/Speed Display
/ Encapsulated water filled motor(No pollution risk)
/ Soft start running makes system’s life longer
/ Thrust bearing system
/ Positive and negative pole reverse connection alarm
/ Over-load/Over-current/Over-voltage/Low-voltage protection
/ Dry protection(No additional float sensor required)
/ A wide range of accessories
Solar Pump End:
Stainless steel: AISI 304 (316 optional)
Non-return valve
Recommend Max Input
Standards:
Note:
* Recommend using 550W solar panels in series
* The Controller is IP 65 Rated however it is recommended that it is not mounted in direct sunlight
* VOC (V) Volts open circuit nothing connected; Vmp (V) Volts maximum power point under load
* Exceeding limits may cause serious harm or irreparable damage
Voltage: 60-450
Power (W): 2200
Max flow (m3/hr): 5.7
Max Head: 190
Diameter: 4″
Outlet: 2″
Solar Panel: 6*410W
Controller type: External/Internal
Impeller: Plastic
