The SDK series pumps are high flow centrifugal pumps designed for the efficient transfer of clean water and non-corrosive fluids. They feature a compact size, exceptional reliability, user-friendly operation, high efficiency, and minimal maintenance requirements. These pumps are well-suited for various applications, including boosting water pressure for residential use, irrigation, and general industrial purposes.

Pumps should be installed in a covered area, protected against the weather.

Stream S2DK30 2.2kW 230V High Flow Centrifugal Pump

The SDK series pumps are high flow centrifugal pumps designed for the efficient transfer of clean water and non-corrosive fluids. They feature a compact size, exceptional reliability, user-friendly operation, high efficiency, and minimal maintenance requirements. These pumps are well-suited for various applications, including boosting water pressure for residential use, irrigation, and general industrial purposes.

Pumps should be installed in a covered area, protected against the weather.

Applications:

• General industrial purposes
• Domestic and commercial hot and cold water distribution systems
• Pressurised water systems
• Non-corrosive liquid movement
• Landscaping and irrigation

Technical Features:

• Max. ambient temperature (inside pump enclosure): 40deg. C
• Max. water operating pressure: 80deg. C
• Max. working pressure: 1000kPa (10 bar)
• Pump body: cast iron
• Motor casing: aluminium
• Closed motor, externally ventilated
• Impeller: Brass
• Mechanical seal: steatite ceramic / metalized carbon
• Insulation class: B/F
• Pump duty: continuous rated

Performance Data (S2DK30):

• Max. suction head: 9m
• Max. operating head (H): 28m
• Max. flow (Q=L/min): 500L/min

Pump Performance Curve:
